Manure Spreader SV/4 140
  • Container dimensions:
        - Lenght: 5,5 mt
        - Height sides: 1,3 mt
  • Load capacity 16 m3
  • Air brakes, hydraulic or both air/hydraulic
  • EC European Certification
  • Independent mechanical suspension or patented hydraulic suspension
  • Nr.2 axles with 10 industrial holes
  • Rear steering axle with hydraulic block
  • Tires:
        - 445/65 R22.5 radial
        - 550/60-22.5 low pressure
        - 560/60 R22.5 radial low pressure
        - 600/50 R22.5 radial low pressure
        - 710/45 R22.5 radial low pressure
  • Nr.1 oleodynamic continuous motion
  • Nr.4 chains
  • Double bottom to eliminate any loss during transportation
  • Hydraulic chain stretcher
  • Nr.4 rear vertical rollers H= 1620 mm complete with teeth cemented interchangeable, nr.5 increased gear boxes
  • Shaft with intermediate shaft drive
  • Hydraulic rear closing/protection system prevents loss of material during transport
  • Automatic rear protection of rollers
  • Hydraulic support foot
  • Eyelet type: F2 ÷ K80 ÷ Twist/Fixed Ø 50 mm
  • Bi-component paint for heavy works ÷ hot galvanized ÷ stainless steel container
  • Complete of cardan with security screw
  • Belong to works with all the compost type
